TZ480 (hardware only)

Firewall inspection throughput:4 Gbps
Threat prevention throughput:2 Gbps
Interfaces:8x1GbE, 2x 5/2.5/1G SFP+
Max. SSL VPN Clients:150
£763.00
(£915.60 inc VAT)
03-SSC-1835
42 item(s)
+ −

The SonicWall TZ480 is part of the new Gen 8 TZ Series which also includes the TZ280, TZ380, TZ580 & TZ680 and available in different bundles.

The latest SonicWall TZ series, are the first desktop form factor next generation firewalls (NGFW) with 10 or 5 Gigabit Ethernet interfaces. The series consist of a wide range of products to suit a variety of use cases.

Designed for small, mid-sized organizations and distributed enterprise with SD-Branch locations, the 8th generation (Gen 8) TZ series delivers industry-validated security effectiveness with best-in-class price performance. These NGFWs address the growing trends in web encryption, connected devices and high-speed mobility by delivering a solution that meets the need for automated, realtime breach detection and prevention.

The Gen 8 TZ series are highly scalable, with high port density of up to 10 ports. It features both inbuilt and an expandable storage of up to 256GB, that enables various features including logging, reporting, caching, firmware backup and more. An optional second power supply provides added redundancy in case of failure on select models.

If unsure which model or bundle is right for you, then please get in touch.

Firewall (Gen 8) Specifications - Firewall General

Operating system:
SonicOS 8
Interfaces:
8x1GbE, 2x 5/2.5/1G SFP+, 1 USB (type-C), 1 console (Micro-USB)
Storage (expansion):
Optional: up to 512 GB
Centralized management:
Network Security Manager (NSM) 3.0 and above, CLI, SSH, Web UI, REST APIs
Logical VLAN and tunnel interfaces (maximum):
128
SAML Single Sign-On (SSO) users:
2,500
Access points supported (maximum):
32

Firewall (Gen 8) Specifications - Firewall/VPN Performance

Firewall inspection throughput:
4 Gbps
Threat prevention throughput:
2 Gbps
Application inspection throughput:
2.2 Gbps
IPS throughput:
2.2 Gbps
Anti-malware inspection throughput:
2.1 Gbps
TLS/SSL inspection and decryption throughput:
650 Mbps
IPSec VPN throughput:
2 Gbps
Connections per second:
18,000
Maximum connections (SPI):
1,200,000
Maximum connections (DPI):
350,000
Maximum connections (TLS):
50,000

Firewall (Gen 8) Specifications - VPN and ZTNA

Site-to-Site VPN tunnels:
200
IPSec VPN client licences (maximum):
5 (200)
SSL-VPN client licences (maximum):
2 (150)
Encryption/authentication:
AES (128, 192, 256-bit)/MD5, SHA-256, SHA-384, Suite B Cryptography
Key exchange:
Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN:
RIP, OSPF, BGP
Certificate support:
Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features:
Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported:
Microsoft Windows 7, Windows 8, Windows 8.1 and Windows 10
NetExtender:
Microsoft Windows 10, Windows 10/11 and Linux
Mobile Connect:
Apple iOS, Mac OS X, Google Android, Chrome OS, Windows
SonicWall Private Access powered by Cloud Secure Edge:
Included in 3&Free Loyalty Program

Firewall (Gen 8) Specifications - Security Services

Deep packet inspection services:
Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, TLS Decryption
Content Filtering Service (CFS):
Reputation-based URL filtering, HTTP URL, HTTPS IP, keyword and content scanning, comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service:
Yes
Application Visualization:
Yes
Capture Advanced Threat Protection:
Yes
Advanced DNS Filtering:
Yes

Firewall (Gen 8) Specifications - Networking

IP address assignment:
Static (DHCP, PPPoE, L2TP and PPTP client), internal DHCP server, DHCP relay
NAT modes:
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols:
BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS:
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication:
LDAP (multiple domains), XAUTH/RADIUS, TACACS+, SAML SSO ¹, RADIUS accounting, NTLM, internal user database, 2FA, Terminal Services, Citrix, Common Access Card (CAC)
Local user database:
250
VoIP:
Full H323 v1.5, SIP
Standards:
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications:
IPv6
High availability:
Active/Standby with stateful synchronization

Firewall (Gen 8) Specifications - Hardware

Form factor:
Desktop
Power supply (W):
60
Maximum power consumption (W):
15.19
Input power:
100-240 VAC, 50-60 Hz
Redundant power supply:
1 (Optional)
Total heat dissipation (BTU):
42.43
Dimensions L x W x H (cm):
22.5 x 14.9 x 3.5
Shipping dimensions L x W x H (cm):
46.3 x 36.8 x 44.2
Weight (kg):
0.82
WEEE weight (kg):
1.18
Shipping weight (kg):
1.41
MTBF @25°C (years):
52.8
Environment (operating/storage):
0°C to +40°C / -40°C to +70°C
Humidity:
5-95% non-condensing

Firewall (Gen 8) Specifications - Regulatory

Regulatory model numbers:
APL72-120
Major regulatory compliance:
FCC Class B, ICES Class B, CE (EMC, LVD, RoHS), UL, cUL, Mexico DGN Notice by UL, ANATEL, WEEE, REACH, SCIP, RCM, MIC Terminal, VCCI Class B, KCC/MSIP, BSMI, MTCTE/TEC, CB

Warranty & Support

Support Cover:
None, optional 24x7 or 8x5
Warranty/Support:
1-Yr hardware/no support or firmware updates
