The SonicWall TZ380 is part of the new Gen 8 TZ Series which also includes the TZ80, TZ280, TZ380, TZ480, TZ580 & TZ680 and available in different bundles.
The Gen 8 TZ series are highly scalable, with high port density of up to 10 ports. It features both in-built and an expandable storage of up to 512 GB, that enables various features including logging, reporting, caching, firmware backup and more. An optional second power supply provides added redundancy in case of failure on select models.
SonicWall TZ Series are designed for small and mid-sized organizations, and distributed enterprises with SD-Branch locations. The latest series deliver best-in-class performance at a low TCO.
Designed for small organizations and lean branches, the TZ380 series deliver industry-validated security effectiveness with best-in-class price-performance.
If unsure which model or bundle is right for you, then please get in touch.
Firewall (Gen 8) Specifications - Firewall General
Operating system:
SonicOS 8
Interfaces:
8x1GbE, 2x 5/2.5/1G SFP+, 1 USB (type-C), 1 console (Micro-USB)
Wireless support:
N/A
Power over Ethernet (PoE) support:
N/A
Storage (expansion):
Optional: up to 512 GB
Centralized management:
Network Security Manager (NSM) 3.0 and above, CLI, SSH, Web UI, REST APIs
Logical VLAN and tunnel interfaces (maximum):
128
SAML Single Sign-On (SSO) users:
1,000
Access points supported (maximum):
16
Firewall (Gen 8) Specifications - Firewall/VPN Performance
Firewall inspection throughput:
3.5 Gbps
NGFW throughput:
N/A
Threat prevention throughput:
1.5 Gbps
Application inspection throughput:
2 Gbps
IPS throughput:
2 Gbps
Anti-malware inspection throughput:
2 Gbps
TLS/SSL inspection and decryption throughput:
600 Mbps
IPSec VPN throughput:
1.6 Gbps
Connections per second:
15,000
Maximum connections (SPI):
1,100,000
Maximum connections (DPI):
250,000
Maximum connections (TLS):
40,000
Firewall (Gen 8) Specifications - VPN and ZTNA
Site-to-Site VPN tunnels:
200
IPSec VPN client licences (maximum):
5 (200)
SSL-VPN client licences (maximum):
2 (100)
Encryption/authentication:
AES (128, 192, 256-bit)/MD5, SHA-256, SHA-384, Suite B Cryptography
Key exchange:
Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN:
RIP, OSPF, BGP
Certificate support:
Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features:
Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported:
Microsoft Windows 7, Windows 8, Windows 8.1 and Windows 10
NetExtender:
Microsoft Windows 10, Windows 10/11 and Linux
Mobile Connect:
Apple iOS, Mac OS X, Google Android, Chrome OS, Windows
SonicWall Private Access powered by Cloud Secure Edge:
Included in 3&Free Loyalty Program
Firewall (Gen 8) Specifications - Security Services
Deep packet inspection services:
Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, TLS Decryption
Content Filtering Service (CFS):
Reputation-based URL filtering, HTTP URL, HTTPS IP, keyword and content scanning, comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service:
Yes
Application Visualization:
Yes
Capture Advanced Threat Protection:
Yes
Advanced DNS Filtering:
Yes
Firewall (Gen 8) Specifications - Networking
IP address assignment:
Static (DHCP, PPPoE, L2TP and PPTP client), internal DHCP server, DHCP relay
NAT modes:
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols:
BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS:
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication:
LDAP (multiple domains), XAUTH/RADIUS, TACACS+, SAML SSO ¹, RADIUS accounting, NTLM, internal user database, 2FA, Terminal Services, Citrix, Common Access Card (CAC)
Local user database:
250
VoIP:
Full H323 v1.5, SIP
Standards:
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications:
IPv6
High availability:
Active/Standby with stateful synchronization
Firewall (Gen 8) Specifications - Hardware
Form factor:
Desktop
Power supply (W):
60
Maximum power consumption (W):
13.77
Input power:
100-240 VAC, 50-60 Hz
Redundant power supply:
1 (Optional)
Total heat dissipation (BTU):
46.95
Dimensions L x W x H (cm):
22.5 x 14.9 x 3.5
Shipping dimensions L x W x H (cm):
46.3 x 36.8 x 44.2
Weight (kg):
0.82
WEEE weight (kg):
1.18
Shipping weight (kg):
1.41
MTBF @25°C (years):
46.4
Environment (operating/storage):
0°C to +40°C / -40°C to +70°C
Humidity:
5-95% non-condensing
Firewall (Gen 8) Specifications - Regulatory
Regulatory model numbers:
APL72-120
Major regulatory compliance:
FCC Class B, ICES Class B, CE (EMC, LVD, RoHS), UL, cUL, Mexico DGN Notice by UL, ANATEL, WEEE, REACH, SCIP, RCM, MIC Terminal, VCCI Class B, KCC/MSIP, BSMI, MTCTE/TEC, CB
Major regulatory compliance (wireless models):
FCC Class B, ICES Class B, CE (EMC, LVD, RoHS), UL, cUL, Mexico DGN Notice by UL, ANATEL, WEEE, REACH, SCIP, RCM, MIC Terminal & Radio, VCCI Class B, KCC/MSIP, BSMI, NCC SRRC, MTCTE/TEC, CB
Major regulatory compliance (PoE models):
N/A
Warranty & Support
Support Cover:
24x7 Support
Warranty/Support:
1-Yr hardware/1-Yr support, firmware updates
