TZ580 Secure Upgrade Plus - Advanced Edition (5 Years)

Firewall inspection throughput:4.5 Gbps
Threat prevention throughput:2.2 Gbps
Interfaces:8x1GbE, 2x 10/5/2.5/1G SFP+
Max. SSL VPN Clients:200
£5,899.00
(£7,078.80 inc VAT)
03-SSC-7458
31 item(s)
+ −

*** This is an upgrade model, used when upgrading from an Eligible SonicWall Product or Eligible Competitive Product ***

The SonicWall TZ580 is part of the new Gen 7 TZ Series which also includes the TZ80, TZ280, TZ380, TZ480 & TZ680 and available in different bundles.

The SonicWall TZ series of firewalls is designed specifically for the needs of SMBs and branch locations, delivering enterprise-class security without the enterprise-grade complexity. With Zero-Touch Deployment and simplified centralized management, installation and operation is easy. Detect sophisticated threats, including encrypted attacks, with advanced networking and security features, like the multi-engine Capture Advanced Threat Protection (ATP) cloud-based sandbox service with patented Real-Time Deep Memory Inspection (RTDMI™).
Simply plug in and enjoy the advanced protection of the cost-effective SonicWall TZ series firewall without worrying about complex management — or the next threat.

Superior Performance
Prevent malicious threats without compromising performance. Deploy next-generation firewalls designed for small, midsize, and distributed enterprises and leverage industry-leading performance in threat prevention and DPI TLS/SSL (Decryption) to protect your networks.

Low Total Cost of Ownership
Make SonicWall TZ firewall the start of enterprise savings. From reduced costs through zero-touch deployment to enabling SD-WAN and delivering threat block rates on par or better than competitors at a fraction of the cost, SonicWall TZ firewalls are security you can’t afford to be without.

Secure SD-WAN Technology
Leave MPLS behind for a more agile, secure, and cost-effective network optimized for today’s broadband-driven, cloud-infused landscape. Eliminate costs on SD-WAN appliances and licenses by leveraging the built-in secure SD-WAN technology in TZ firewalls to

Simplified Centralized Management
Increase efficiencies in deploying and managing distributed firewalls via configuration administration enhancements and bulk deployment capabilities, including auto-sync, multi-tenant commit and deploy, and bulk password change.

Advanced Reporting & Analytics
Increase insights and enhance visibility with reporting templates, real-time reports, customizable reports, schedule report capability, and tenant-based analytics.

Managed Protection Security Suite (MPSS)
Extend your team with SonicSentry NOC Team 24x7 for managed firewall services that include monitoring, firmware updates, vulnerability reporting, and an embedded warranty of up to $200K warranty.

Integrates with Wireless Access Points
Implement high-speed wireless security by combining a TZ series next-generation firewall with a SonicWall SonicWave wireless access point. TZ series firewalls and SonicWave access points both feature 2.5/5 GbE ports that enable multi-gigabit wireless throughput offered in Wi-Fi 6 wireless technology.

Built-in ZTNA Connector
Increase secure access to private applications behind the firewalls using a built-in connector to Cloud Secure Edge, enabling compliance with a Zero-Trust framework.

If unsure which model or bundle is right for you, then please get in touch.

Firewall (Gen 8) Specifications - Firewall General

Operating system:
SonicOS 8
Interfaces:
8x1GbE, 2x 10/5/2.5/1G SFP+, 1 USB (type-C), 1 console (Micro-USB)
Wireless support:
N/A
Power over Ethernet (PoE) support:
N/A
Storage (expansion):
Optional: up to 512 GB
Centralized management:
Network Security Manager (NSM) 3.0 and above, CLI, SSH, Web UI, REST APIs
Logical VLAN and tunnel interfaces (maximum):
256
SAML Single Sign-On (SSO) users:
2,500
Access points supported (maximum):
32

Firewall (Gen 8) Specifications - Firewall/VPN Performance

Firewall inspection throughput:
4.5 Gbps
NGFW throughput:
N/A
Threat prevention throughput:
2.2 Gbps
Application inspection throughput:
2.5 Gbps
IPS throughput:
2.5 Gbps
Anti-malware inspection throughput:
2.3 Gbps
TLS/SSL inspection and decryption throughput:
750 Mbps
IPSec VPN throughput:
2.2 Gbps
Connections per second:
20,000
Maximum connections (SPI):
1,400,000
Maximum connections (DPI):
500,000
Maximum connections (TLS):
60,000

Firewall (Gen 8) Specifications - VPN and ZTNA

Site-to-Site VPN tunnels:
250
IPSec VPN client licences (maximum):
10 (500)
SSL-VPN client licences (maximum):
2 (200)
Encryption/authentication:
AES (128, 192, 256-bit)/MD5, SHA-256, SHA-384, Suite B Cryptography
Key exchange:
Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN:
RIP, OSPF, BGP
Certificate support:
Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features:
Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported:
Microsoft Windows 7, Windows 8, Windows 8.1 and Windows 10
NetExtender:
Microsoft Windows 10, Windows 10/11 and Linux
Mobile Connect:
Apple iOS, Mac OS X, Google Android, Chrome OS, Windows
SonicWall Private Access powered by Cloud Secure Edge:
Included in 3&Free Loyalty Program

Firewall (Gen 8) Specifications - Security Services

Deep packet inspection services:
Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, TLS Decryption
Content Filtering Service (CFS):
Reputation-based URL filtering, HTTP URL, HTTPS IP, keyword and content scanning, comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Comprehensive Anti-Spam Service:
Yes
Application Visualization:
Yes
Capture Advanced Threat Protection:
Yes
Advanced DNS Filtering:
Yes

Firewall (Gen 8) Specifications - Networking

IP address assignment:
Static (DHCP, PPPoE, L2TP and PPTP client), internal DHCP server, DHCP relay
NAT modes:
1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols:
BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS:
Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication:
LDAP (multiple domains), XAUTH/RADIUS, TACACS+, SAML SSO ¹, RADIUS accounting, NTLM, internal user database, 2FA, Terminal Services, Citrix, Common Access Card (CAC)
Local user database:
250
VoIP:
Full H323 v1.5, SIP
Standards:
TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications:
IPv6
High availability:
Active/Standby with stateful synchronization

Firewall (Gen 8) Specifications - Hardware

Form factor:
Desktop
Power supply (W):
60
Maximum power consumption (W):
15.6
Input power:
100-240 VAC, 50-60 Hz
Redundant power supply:
1 (Optional)
Total heat dissipation (BTU):
56.74
Dimensions L x W x H (cm):
22.5 x 14.9 x 3.5
Shipping dimensions L x W x H (cm):
46.3 x 36.8 x 44.2
Weight (kg):
0.97
WEEE weight (kg):
1.42
Shipping weight (kg):
1.93
MTBF @25°C (years):
30.7
Environment (operating/storage):
0°C to +40°C / -40°C to +70°C
Humidity:
5-95% non-condensing

Firewall (Gen 8) Specifications - Regulatory

Regulatory model numbers:
APL72-120
Major regulatory compliance:
FCC Class B, ICES Class B, CE (EMC, LVD, RoHS), UL, cUL, Mexico DGN Notice by UL, ANATEL, WEEE, REACH, SCIP, RCM, MIC Terminal, VCCI Class B, KCC/MSIP, BSMI, MTCTE/TEC, CB
Major regulatory compliance (wireless models):
N/A
Major regulatory compliance (PoE models):
N/A

Warranty & Support

Support Cover:
24x7 Support
Warranty/Support:
5-Yr hardware/5-Yr support, firmware updates
